DELLOK 1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe

N/A Contact us for details
MOQ
N/A Contact us for details
Price
DELLOK 1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
Delivery Condition: Pickled / Bright Annealed
Standard:: A213/ASME SA213, ASTM A789,
OD:: 6-609.6mm WT: 0.6-50mm
Eddy Current Testing: Done To Detect Homogeneities In Subsurface By Using Digital Flaw-mark Testing System
Chemical Analysis: Test Done As Per Required Quality Standards
WT:: 0.6-50mm
High Light:

TP316Ti Round Stainless Steel Pipe

,

A213 Round Stainless Steel Tube

,

1.65mm Stainless Steel Pipes

Basic Infomation
Place of Origin: China
Brand Name: DELLOK
Certification: CE. ISO,EN10204. 3.1 Cert.
Model Number: Flat tube
Payment & Shipping Terms
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: EX-WORK within 4~5 weeks after order
Payment Terms: L/C, T/T Contact us for details
Supply Ability: 60000 meters month
Product Description

1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe



Stainless Steel Seamless Tube A213 TP316Ti , 0.89mm, 1.24mm, 1.65mm,



Standard: ASTM A213/ASME SA213, ASTM A789, ASME SA789 , SB677

More Material: TP304/304L , TP310S/310H, TP316/316L,TP316Ti, TP317/317L, TP321/321H, TP347/347H, 904L

OD:6mm-152mm

Thickness: 0.6mm-30mm



Heat Exchanger TP304 / 304L TP310 /310S TP316 / 316L TP317 /317L TP321 /321H TP347H UNS NO8904 / 904L Stainless Steel Seamless Tube ASTM A213 / ASME SA213 ASTM B677 / ASME SB677



MAIN STEEL TYPE AND GRADE :

PRODUCTS TYPICAL STEEL GRADE
Austenitic

TP304,TP304L,TP304H,TP316,TP316L,TP316H,TP316Ti

TP321,TP321H,TP347H,904L,TP310H,TP310S,TP317,TP317L

Duplex / Super Duplex S31803, S32205, S32750, S32760, S31500, S32304, S31254



MAIN PRODUCTION STANDARDS:

STANDARD TYPE STANDARD
EN EN10216-5 , EN10216-2
DIN DIN 17456 , DIN 17458
ASTM ASTM A312, A213, A269, A511, A789, A790 ETC
GOST GOST 9941 , GOST 5632
JIS JIS G3459 , JIS G3463
GB GB/T14975,GB/T14975, GB13296, GB5310, GB9948



Stainless Steel Seamless Pipe/ Tube:
1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include “Logo(YHSS)+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
8.MTC: BWSS Official Original MTC paper will be supplied for each order.



PACKING: By Bundle / By Wooden Yoke / By Wooden Case



APPLICATIONS FIELD :

1. Pipe and Tubes for petrochemical industry

2. Pharmaceutical industry
3. Food industry
4. Aviation and aerospace industry
5. Architectural decoration industry



Our Service:
1. Inquiry-Professional quotation, or send inquiry item more details, we start contact more details
2. Confirm the price, lead time, payment term etc
3. Our sales send the Proforma Invoice with our seal, or you order online to us
4. Customer make the payment for deposit and send us Bank receipt
5. Initial Production Stage-Inform the clients that we have got the payment, and will make the samples according to your request, send you photos or samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time
6. Middle Production-send photos to show the production line which you can see you products. Confirm the estimated delivery time again.
7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party inspection
8. Clients make payment for balance and ship goods, inform the tracking number and check the status for clients
9. Order can be say "finish" when you receive the goods and satisfy with them
10. Feedback to our about Quality, Service, Market Feedback & Suggestion. And we can do better



DELLOK 1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe 0DELLOK 1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe 1DELLOK 1.65mm Seamless A213 TP316Ti Round Stainless Steel Pipe 2
