DELLOK SMLS Titanium Spiral 16.5mm B338 Threaded Aluminum Pipe
EN10204 Threaded Aluminum Pipe
,EN10204 Aluminum Fin Tube
,16.5mm Aluminum Alloy Pipe
SMLS Titanium Spiral 16.5mm B338 Threaded Aluminum Pipe
B338 Gr. 2 SMLS Titanium Tube , 1.245mmWT , Extruded Spiral Aluminum Fin Tube
ASTM B338: Seamless and Welded Titanium and Titanium Alloy Tubes for Condensers and Heat Exchangers
Detail:
|
General extrusion production capacity |
General specifications of DR Type-Extruded Fin Tubes |
|
Extrusion Facility: 10 finning machines. |
Tube OD: 50.8mm(2'') max. |
Introduction:
A smooth core tube is inserted into an aluminum sleeve and then the fins are extruded out of the aluminum sleeve. The fins are solid plain or serrated into 12, 16 or 24 segments or as your design. And both plain ends with appr. 10mm~50mm and gaps (Unfinned Section) in the middle. All the goods shall be Zinc or Aluminum that metallized applied by an electro spray arc system coating on surface. Besides, we provide Tube Support Box, Clamp or Spacer Box(Materials: Aluminum, Zinc or Stainless Steel).
Applications:
Heat exchangers units for power plant(electric, nuclear, thermal and geothermal power plants);
High corrosive systems (condensers, evaporators, sea water desalinations, fertilizing, urea systems, ammonia, gas, corrosive acids);
The petroleum, chemical and petrochemical industries;
The food processing and refrigeration industries;
Natural gas treatment
Specifications:
Extruded Bimetallic Finned Tube is combined with two different materials.
|
Items |
General Materials |
Popular ASTM Materials |
|
Core Tube Material |
Any metallic materials, as carbon steel, low-alloy steel, |
1. Carbon Steel: A179, A192,SA210 Gr A1/C,A106 Gr B |
|
Fins Material |
1. Aluminum |
1. Aluminum(Alu.1100,Alu.1060,Alu.6063) |
|
All dimensions are in Inches and specification upon your requests. |
|||
|
Tube OD |
Fin Height |
Fin Thickness |
Fins per Pitch(Density) |
|
5/8 |
3/8,1/2 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10, 11, 12 |
|
3/4 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10, 11, 12 |
|
1 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10, 11 |
|
1 1/4 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10, |
|
1 1/2 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10, 11 |
|
1 3/4 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10 |
|
2 |
3/8,1/2,5/8 |
.015/.016/ .020 |
4, 5, 6, 7, 8, 9, 10 |
|
Please email us for more information. |
|||
Our Service:
1. Inquiry-Professional quotation, or send inquiry item more details
2. Confirm the price, lead time, payment term etc
3. Proforma Invoice send or online
4. Make the samples according to your request, send you photos or samples, arrange the production
5. Send the production line photos Confirm the estimated delivery time again.
6. End Production-Mass production products photos and samples will send to you for approval.
7. Inform the tracking number and check the status for clients
8. Order can be say "finish" when you receive the goods and satisfy with them
9. Feedback to our about Quality, Service, Market Feedback & Suggestion. And we can do better
