TP304L Stainless Steel Embedded Fin Tube with 0.4mm Fin Thickness and 12FPI Fin Pitch G-Fin Tube

Place of Origin:China
Brand Name:DELLOK
Certification:CE. ISO,EN10204. 3.1 Cert.
Model Number:G Fin
Minimum Order Quantity:N/A Contact us for details
Price:N/A Contact us for details
Payment Terms:L/C, T/T Contact us for details
Supply Ability:60000 meters month
Product Details
Highlight:

0.4mm Embedded Fin Tube

,

16.5mm Steel Fin Tube

,

16.5mm Embedded Fin Tube

Tube OD:: 50.8mm(2'') Max.
Tube Length:: 18,000mm Max.
Fin Height:: 16.5 Mm Max.
Fin Thickness:: Generally 0.4mm ~0.6mm
Fin Pitch:: 2.1 Mm (12FPI) Min.
Daily Capacity: Up To 3500 Meters.
Product Description
Product Overview

The Aluminum Copper SMLS Stainless Steel TP304L Embedded Fin Tube is a high-performance heat transfer component engineered for demanding industrial applications. Aluminum and copper fins are embedded into a seamless stainless steel tube of TP304 / TP304L, delivering exceptional thermal efficiency and corrosion resistance.

Core Tube Material: Seamless Stainless Steel TP304 / TP304L

Fin Materials: Aluminum & Copper

Fin Type: G-Fin Embedded (Grooved)

Standards: ASTM A213 / A213M, ASTM A/ASME SA213/A249/A269/A312

General Specifications
ParameterSpecification
Tube OD50.8 mm (2") max.
Tube Length18,000 mm max.
Fin Height16.5 mm max.
Fin ThicknessGenerally 0.4 mm ~ 0.6 mm
Fin Pitch2.1 mm (12 FPI) min.

Production Capacity: 5 G-Fin finning machines with a daily capacity of up to 3,500 meters.

Construction & Manufacturing

The aluminum fin strip is tension-wound and placed into a groove cut into the tube. The groove depth is approximately 0.4 mm. All goods are zinc or aluminum metalized using an electro-spray arc system coating on the surface.

Tubes are delivered with square-cut ends, free of burrs, internally dried and air-blown clean, and externally coated with varnish at both ends. Desiccants are placed in each package for continental transportation.

Acceptance Criteria: API Standard 661 (Air-Cooled Heat Exchangers for General Refinery Service) or the specified delivery conditions.

Material Specifications
ItemGeneral MaterialsPopular ASTM Materials
Core Tube MaterialCarbon steel, low-alloy steel, stainless steel, brass, copper, copper-nickel alloys, aluminum bronze, nickel alloys. 1. Carbon Steel: A179, A192, SA210 Gr A1/C, A106 Gr B
2. Stainless Steel: TP304/304L, TP316/TP316L/316Ti, A789 S31803/S2205, etc.
3. Copper: UNS12200/UNS14200/UNS70600, CuNi 70/30, CuNi 90/10
Fins Material1. Aluminum
2. Copper
1. Aluminum (Alu. 1100, Alu. 1060)
2. Copper
Dimensional Range

All dimensions are in inches. Specifications can be customized upon request.

Tube ODFin HeightFin ThicknessFins per Pitch (Density)
5/8"3/8", 1/2".015 / .016 / .0206, 7, 8, 9, 10, 11, 12
3/4"5/8", 1/2".015 / .016 / .0206, 7, 8, 9, 10, 11, 12
1"5/8", 1/2".015 / .016 / .0206, 7, 8, 9, 10, 11, 12
1 1/4"5/8", 1/2".015 / .016 / .0206, 7, 8, 9, 10, 11, 12
1 1/2"5/8", 1/2".015 / .016 / .0206, 7, 8, 9, 10, 11, 12

Please email us for more information.

Applications
  • Heat exchanger units for power plants (electric, nuclear, thermal, and geothermal)
  • High-corrosive systems (condensers, evaporators, seawater desalination, fertilizing, urea systems, ammonia, gas, corrosive acids)
  • Petroleum, chemical, and petrochemical industries
  • Food processing and refrigeration industries
  • Natural gas treatment

We also provide tube support boxes, clamps, and spacer boxes in Aluminum, Zinc, and Stainless Steel.

Our Service Process
  1. Inquiry: Professional quotation provided, or send us more details on your inquiry item so we can start discussing specifics.
  2. Confirmation: Confirm price, lead time, payment terms, and other details.
  3. Proforma Invoice: Our sales team sends the Proforma Invoice with our seal, or you can place your order online.
  4. Deposit Payment: Customer makes the deposit payment and sends us the bank receipt.
  5. Initial Production: We inform clients that payment has been received and produce samples per your request. Photos or samples are sent for your approval. After approval, we arrange production and inform you of the estimated timeline.
  6. Mid-Production: Photos of the production line are sent so you can see your products. Estimated delivery time is confirmed again.
  7. Final Production: Mass production photos and samples are sent for your approval. You may also arrange third-party inspection.
  8. Balance Payment & Shipping: Client pays the balance and ships goods. We provide the tracking number and monitor the status for you.
  9. Order Completion: The order is considered "finished" when you receive the goods and are satisfied with them.
  10. Feedback: Share your feedback on quality, service, market insights, and suggestions so we can continue to improve.
Product Gallery
Aluminum copper embedded fin tube with grooved G-fin construction on stainless steel TP304L core tube
Close-up view of embedded fin tube showing aluminum fin strip tension-wound into tube groove
Stainless steel TP304L embedded fin tube bundle ready for heat exchanger assembly
