DELLOK Seamless Steel OD 25.4mm C12200 Copper Fin Heat Exchanger

N/A Contact us for details
MOQ
N/A Contact us for details
Price
DELLOK Seamless Steel OD 25.4mm C12200 Copper Fin Heat Exchanger
Features Gallery Product Description Request A Quote
Features
Specifications
Fin Tube Type: L Type Fin Tube,Tension Wound L Type Fin Tube
Fin Material: C12200
Tube Material: ASME B111 C70600
Tube Size: OD 25.4mm X1.245mmWT
Fin O.D.: 57.15mm
Fin Thickness:: 0.4mm
High Light:

C12200 Copper Fin Heat Exchanger

,

C12200 Fin And Tube Heat Exchanger

,

OD 25.4mm Seamless Steel Pipe

Basic Infomation
Place of Origin: China
Brand Name: DELLOK
Certification: CE. ISO,EN10204. 3.1 Cert.
Model Number: L TYPE
Payment & Shipping Terms
Packaging Details: Steel frame case sealed by plywoods with each tube end capped
Delivery Time: As per clients' request if any urgent.
Payment Terms: L/C, T/T Contact us for details
Supply Ability: 60000 meters month
Product Description

Seamless Steel OD 25.4mm C12200 Copper Fin Heat Exchanger ​


L Type fin tube, core tube material C70600, OD25.4X1.245 with copper fins material C12200



ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock



Quick Detail:

Special order with fastest delivery within 2 weeks for power plant in Saui Arabia in Sep of 2015.



(1) All detailed order specifications as below.

Tube material: ASME B111 C70600
Tube Size :OD 25.4mm X1.245mmWT
Fin material: C12200
Fin O.D. : 57.15mm
Fin thickness: 0.4mm
Fin height: 15.8mm
Fin per inch: 11

Plain ends: 25.4mm+50.8mm



(2) Manufacturing process:

The copper strip is folded into an L SHAPE and wound onto the base tube surface under tension.

The feet of the fins are joined together and cover the finned surface.



(3) Delivery Condition

Tube ends are square cut, free burrs, internally dried and air blown clean.



(4) Packing

The desiccants are put into each package for continental transportation as well.



(5) Applications

An urgent replancement job during the shutdown of power plant.



(6) Other Specifications

All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch

5/8

3/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

3/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/2

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

Pease email us for more information.



Quick Details
Condition: New Brand Name: YONGHUI
Place of Origin: China Material: Aluminum
Packing: Steel frame with plywoods or seaworthy wooden box. Marketing Type: New Production 2020
Warranty: 1 Year After Warranty Service: Online support
Machinery Test Report: Provided Certification: CE. ISO,EN10204. 3.1 Cert.
After-sales Services: Video technical support, Online support Showroom Location: None
Local Service Location: None
