A213 Alloy Steel Oil Refinery T5 T9 T11 SMLS Studded Pipe
A213 T5 / T9 / T11 / T12 SMLS alloy steel , NPS 3''(88.9mm) studded tubes for oil refinery
ASTM A213 / A213M :
Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
Manufacturing process:
Studs are fully automatically welded onto the tube by resistance welding. It include two types :Cylindrical or elliptical. And we can provide the raw materials mill certificates, inspection and test samples results and warranty certificate of manufacturer.
Acceptance criteria
Approved drawings and the delivery conditions (TDC) of clients.
Delivery condition
Tube ends are square cut, free burrs, internally dried and air blown clean, externally coated with varnish at both ends of extruded bimetallic fin tube.
surface with Oil dip, black coating or varnish.
Applications:
Furnace
Chemical
Petrochemical industry
Power station etc.
|
Product Details |
|
|
Material: |
Carbon, stainless, and alloy steels. |
|
Tube details: |
Tube Thickness:4mm~15mm |
|
Tube Length:16 meters max |
|
|
Tube OD: 219 mm max |
|
|
Studs Height:10mm Min. |
|
|
Studs OD:OD6mm~OD16mm |
|
|
Production Capacity: |
Daily capacity up to 80,000 studs; |
|
Executive Standard |
ASTM A213/A213M |
|
|
Materials Grade |
T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T23, T24, T36, T91, T92, T122, T911 |
|
Material Grade and Chemical Composition(％):
|
Grade |
C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
V≥ |
|
T11 |
0.05-0.15 |
0.30-0.60 |
0.025 |
0.025 |
0.50-1.00 |
0.50-1.00 |
1.00-1.50 |
|
|
T12 |
0.05-0.15 |
0.30-0.61 |
0.025 |
0.025 |
≤0.50 |
0.80-1.25 |
0.44-0.65 |
|
|
T13 |
0.05-0.15 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
1.90-2.60 |
0.87-1.13 |
|
|
T2 |
0.10-0.20 |
0.30-0.61 |
0.025 |
0.025 |
0.10-0.30 |
0.50-0.81 |
0.44-0.65 |
|
|
T5 |
≤0.15 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
4.00-6.00 |
0.45-0.65 |
|
|
T5b |
≤0.15 |
0.30-0.60 |
0.025 |
0.025 |
1.00-2.00 |
4.00-6.00 |
0.45-0.65 |
|
|
T5c |
≤0.12 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
4.00-6.00 |
0.45-0.65 |
|
|
T9 |
≤0.15 |
0.30-0.60 |
0.025 |
0.025 |
0.25-1.00 |
8.00-10.00 |
0.9-1.0 |
|
|
T22 |
0.05-0.15 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
1.90-2.60 |
0.87-1.13 |
|
|
T91 |
0.08-0.12 |
0.30-0.60 |
0.020 |
0.010 |
≤0.50 |
8-9.50 |
0.85-1.05 |
0.18-0.25 |
|
T92 |
0.07-0.13 |
0.30-0.60 |
0.020 |
0.010 |
≤0.50 |
8-9.50 |
0.3-0.60 |
0.15-0.25 |
|
T21 |
0.05-0.15 |
0.30-0.60 |
0.025 |
0.025 |
≤0.50 |
2.65-3.35 |
0.80-1.06 |
|
Specifications:
|
Items |
General Materials |
Popular ASTM /ASME Materials |
|
Core Tube Material |
Carbon Steel Alloy Steel Heat Resistant Steel, Stainless Steel |
1. Carbon Steel: A106 Gr. B 2. Stainless Steel: TP304/304L,TP316/TP316L, TP347 3. Alloy Steel: P5,T5,P9,T9,T11,T22 |
|
Studs Material |
Carbon Steel Stainless Steel |
1. Carbon Steel 2. Stainless Steel: TP409/410,TP304/304L,TP316/TP316L, TP321/TP321L |
Dimensions Data Sheet We're Supplying.
|
General Descriptions of Studded tubes |
Popular Specifications we make |
|
Tube OD(mm) |
OD38mm~OD219mm |
|
Tube Wall Thickness(mm) |
4mm~15mm |
|
Tube Length(mm) |
16,000mm Max. |
|
Studs OD(mm) |
OD6mm~OD16mm |
|
Studs Height(mm) |
10mm~45mm |
|
Please email us for more information as your request. |
|
Competitive Advantage:
We have more than 10,000 square meters workshop, including 3 finning machines, daily extrusion capacity up to 80,000 studs.
Shanghai Port is our nearest seaport and airport, less than 2 hours’ drive away from our workshop, convenient transportation.
Due to their high rigidity, studded tubes can be used even under extreme temperature and pressure conditions.
