Dellok High quality DIN 2448 ST 37 Carbon Seamless Steel Pipe
About Us
Dellok(YONGHUI) products are widely used in petroleum, chemical, natural gas, metallurgy, electric power, grain and oil machinery, food freezing and automobile industries. High-quality products and perfect after-sales service have been praised, favored and supported by users in China and abroad. Dellok(YONGHUI) promises that we regard customers' needs and opinions as work goals, and serve customers with a conscious behavior and potential consciousness at the base of 100% sincerity, quality, and service. Dellok(YONGHUI) has now developed into a professional manufacturing enterprise integrating scientific research, manufacturing and sales. Dellok(YONGHUI) people will, as always, use advanced high-tech products and dedicated business philosophy to serve the whole society.
Products Description
| product name | .Material | .Standard. | .Size(mm) | |
| Low temperature tube | 16MnDG 10MnDG 09DG 09Mn2VDG 06Ni3MoDG ASTM A333 |
GB/T18984-
2003
ASTM A333
|
OD:8-1240* WT:1-200 |
|
| High-pressure boiler tube | 20G ASTMA106B ASTMA210A ST45.8-III |
GB5310-1995 ASTM SA106 ASTM SA210 DIN17175-79 |
OD:8-1240* WT:1-200 |
|
| Petroleum cracking tube | 10 20 |
GB9948-2006 | OD: 8-630* WT:1-60 |
|
| Low medium pressure boiler tube | 10# 20# 16Mn,Q345 |
GB3087-2008 | OD:8-1240* WT:1-200 |
|
|
General structure
of the tube
|
10#,20#,45#,27SiMn ASTM A53A,B 16Mn,Q345 |
GB/T8162- 2008 GB/T17396- 1998 ASTM A53 |
OD:8-1240* WT:1-200 |
|
| Oil casing | J55,K55,N80,L80 C90,C95,P110 |
API SPEC 5CT ISO11960 |
OD:60-508* WT:4.24-16.13 |
Products details
| API Casing | |||||||||||
| Size | Grade and Connection | Standards | |||||||||
| OD mm (in) | WT/mm | H40 | J55 K55 | M65 | L80-1 R95 | N80-1 N80Q | C90 T95 | C110 | P110 | Q125 | |
| 114.3(4.5') | 5.21 | S | S | S | API SPEC 5CT/ISO11960 | ||||||
| 5.69 | S/B | S/B | |||||||||
| 6.35 | S/L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 7.37 | L/B | L/B | L/B | L/B | L/B | ||||||
| 8.56 | L/B | L/B | |||||||||
| 127(5') | 5.59 | S | S | ||||||||
| 6.43 | S/L/B | S/L/B | |||||||||
| 7.52 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 9.19 | L/B | S/L/B | S/L/B | L/B | S/L/B | L/B | |||||
| 11.1 | L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 12.14 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | L/B | ||||||
| 139.7(5.5') | 6.2 | S | S | S | |||||||
| 6.98 | S/L/B | S/L/B | |||||||||
| 7.72 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 9.17 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 10.54 | L/B | S/L/B | S/L/B | L/B | S/L/B | S/L/B | |||||
| 168.28(6.625') | 7.32 | S | S/L/B | S/L/B | |||||||
| 8.94 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 10.59 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 12.06 | S/L/B | S/L/B | L/B | S/L/B | L/B | ||||||
| 177.8(7') | 6.91 | S | S | S | |||||||
| 8.05 | S/L/B | L/B | S/L/B | S/L/B | L/B | ||||||
| 9.19 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 10.36 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 11.51 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 12.65 | S/L/B | S/L/B | L/B | S/L/B | S/L/B | ||||||
| 13.72 | S/L/B | S/L/B | L/B | S/L/B | S/L/B | ||||||
| 193.68(7.625') | 8.33 | S/L/B | S/L/B | L/B | L/B | L/B | |||||
| 9.52 | L/B | L/B | L/B | L/B | L/B | ||||||
| 10.92 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | L/B | ||||||
| 14.27 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.11 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.88 | L/B | L/B | L/B | L/B | L/B | ||||||
| 219.08(8.625') | 6.71 | S | S | S | |||||||
| 7.72 | S | S/L/B | S | ||||||||
| 8.94 | S | S/L/B | S/L/B | ||||||||
| 10.16 | S/L/B | L/B | L/B | L/B | L/B | ||||||
| 11.43 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | |||||||
| 14.15 | L/B | L/B | L/B | L/B | L/B | ||||||
| 244.48(9.625') | 8.94 | S | S/L/B | S/L/B | |||||||
| 10.03 | S/L/B | S/L/B | L/B | L/B | L/B | L/B | |||||
| 11.05 | L/B | L/B | L/B | L/B | L/B | ||||||
| 11.99 | L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 13.84 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.11 | L/B | L/B | L/B | L/B | |||||||
| 273.05(10.75') | 8.89 | S/B | S/B | ||||||||
| 10.16 | S/B | S/B | S/B | ||||||||
| 11.43 | S/B | S/B | S/B | S/B | S/B | S/B | S/B | ||||
| 12.57 | S/B | S/B | S/B | S/B | |||||||
| 13.84 | S/B | S/B | S/B | ||||||||
| 15.11 | S/B | S/B | S/B | ||||||||
| 298.45(11.75') | 9.65 | ||||||||||
| 10.92 | |||||||||||
| 12.19 | S/B | S/B | |||||||||
| 13.06 | S/B | S/B | S/B | ||||||||
| 339.72(13.375') | 8.38 | S | |||||||||
| 9.65 | S/B | S/B | |||||||||
| 10.92 | S/B | S/B | |||||||||
| 12.19 | S/B | S/B | S/B | S/B | S/B | ||||||
| 13.06 | S/B | S/B | S/B | S/B | S/B | ||||||
| 406.4(16') | 16.66 | ||||||||||
| 508(20') | 16.13 | S/L/B | |||||||||
| Note: S-SC;L-LC;B-BC. | |||||||||||
| API Tubing | |||||||||||
| Size | Grade and Connection | Standards | |||||||||
| OD mm (in) | WT/mm | H40 | J55 | L80-1 R95 | N80-1 N80Q | C90 | T95 | P110 | |||
| 42.16(1.66') | 3.18 | API SPEC 5CT/ISO11960 | |||||||||
| 3.56 | N/U | N/U | N/U | N/U | N/U | N/U | |||||
| 4.85 | U | U | U | U | U | U | U | ||||
| 48.26(1.9') | 3.18 | N/U | N/U | N/U | N/U | N/U | N/U | ||||
| 3.68 | N/U | N/U | N/U | N/U | N/U | N/U | |||||
| 5.08 | U | U | U | U | U | U | U | ||||
| 6.35 | |||||||||||
| 7.62 | |||||||||||
| 60.32(2.375') | 4.24 | ||||||||||
| 4.83 | |||||||||||
| 6.45 | |||||||||||
| 7.49 | |||||||||||
| 8.53 | |||||||||||
| 73.02(2.875') | 5.51 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | |||
| 7.01 | N/U | N/U | N/U | N/U | N/U | ||||||
| 7.82 | N/U | N/U | N/U | N/U | N/U | ||||||
| 8.64 | U | U | |||||||||
| 9.96 | |||||||||||
| 11.18 | U | N | N | N | N | N | |||||
| 88.9(3.5') | 5.49 | ||||||||||
| 6.45 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | ||||
| 7.34 | N | N | N | N | N | N | |||||
| 9.52 | N/U | N/U | N/U | N/U | N/U | ||||||
| 10.92 | |||||||||||
| 12.09 | |||||||||||
| 13.46 | |||||||||||
| 101.6(4') | 5.74 | N | N | N | N | N | N | N | |||
| 6.65 | U | U | U | U | U | U | U | ||||
| 8.38 | |||||||||||
| 10.54 | |||||||||||
| 12.7 | |||||||||||
| 15.49 | |||||||||||
| 114.3(4.5') | 6.88 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | |||
| 8.56 | |||||||||||
| 9.65 | |||||||||||
| 10.92 | |||||||||||
| 12.7 | |||||||||||
| 14.22 | |||||||||||
| 16 | |||||||||||
| Note: N-NU; U-EU. | |||||||||||
| Chemical Analysis(%) For Part Standard | ||||||||||||||||
| Standard | Class | Grade | Type | C | Mn | Mo | Cr | Ni | Cu | P | S | Si | ||||
| min | max | min | max | min | max | min | max | max | max | max | max | max | ||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | |
| API 5CT | 1 | H40 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |
| J55 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| K55 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| N80 | 1 | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| N80 | Q | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| 2 | M65 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | ||
| L80 | 1 | - | 0.43 | - | 1.9 | - | - | - | - | 0.25 | 0.35 | 0.03 | 0.03 | 0.45 | ||
| L80 | 9Cr | - | 0.15 | 0.3 | 0.6 | 0.9 | 1.1 | 8 | 10 | 0.5 | 0.25 | 0.02 | 0.01 | 1 | ||
| L80 | 13Cr | 0.15 | 0.22 | 0.25 | 1 | - | - | 12 | 14 | 0.5 | 0.25 | 0.02 | 0.01 | 1 | ||
| C90 | 1 | - | 0.35 | - | 1.2 | 0.25 | 0.85 | - | 1.5 | 0.99 | - | 0.02 | 0.01 | - | ||
| C90 | 2 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.01 | - | ||
| C95 | - | - | 0.45 | - | 1.9 | - | - | - | - | - | - | 0.03 | 0.03 | 0.45 | ||
| T95 | 1 | - | 0.35 | - | 1.2 | 0.25 | 0.85 | 0.4 | 1.5 | 0.99 | - | 0.02 | 0.01 | - | ||
| T95 | 2 | - | 0.5 | - | 1.9 | - | - | - | - | 0.99 | - | 0.03 | 0.01 | - | ||
| 3 | P110 | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| 4 | Q125 | 1 | - | 0.35 | - | 1.35 | - | 0.85 | - | 1.5 | 0.99 | - | 0.02 | 0.01 | - | |
| Q125 | 2 | - | 0.35 | - | 1 | - | NL | - | NL | 0.99 | - | 0.02 | 0.02 | - | ||
| Q125 | 3 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.01 | - | ||
| Q125 | 4 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.02 | - | ||
| Tensile Property For Part Standard | |||||||||||
| Standard | Class | Grade | Type | Elongation(%) | Yield Strengh(Mpa) | Tensile Strengh(Mpa) | Hardness(Max) | Required WT | Allowed Tolerance of Hardness | ||
| Min | Max | Min | HRC | HBW/- | mm | HRC | |||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | |
| API 5CT | 1 | H40 | 0.5 | 276 | 552 | 414 | - | - | - | - | |
| J55 | - | 0.5 | 379 | 552 | 517 | - | - | - | - | ||
| K55 | - | 0.5 | 379 | 552 | 655 | - | - | - | - | ||
| N80 | 1 | 0.5 | 552 | 758 | 689 | - | - | - | - | ||
| N80 | Q | 0.5 | 552 | 758 | 689 | - | - | - | - | ||
| 2 | M65 | - | 0.5 | 448 | 586 | 586 | 22 | 235 | - | - | |
| L80 | 1 | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| L80 | 9Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| L80 | 13Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | ≤12.70 | 3 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | 12.71~19.04 | 4 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | 19.05~25.39 | 5 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | ≥25.40 | 6 | ||
| C95 | - | 0.5 | 655 | 758 | 724 | - | - | - | - | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | ≤12.70 | 3 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | 12.71~19.04 | 4 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | 19.05~25.39 | 5 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | ≥25.40 | 6 | ||
| 3 | P110 | - | 0.6 | 758 | 965 | 862 | - | - | - | - | |
| 4 | Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | ≤12.70 | 3 | |
| Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | 12.71~19.04 | 4 | ||
| Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | ≥19.05 | 5 | ||
Size
Related Standard & Specification: API 5CT, ISO 11960, API 5B, GOST
Related Grade: J55, K55, N80, L80-1, L80-9Cr, L80-13Cr, P110, Q125, K55 D10, L80 D10.
Available Approved Marine: ABS / BV / LR / DNV / GL / KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Hot Rolled, Cold Drawn, Hot Expanded.
Accessories: Pup Joint, Coupling (Coupling Stock), Blast Joint, Crossover etc.
Connection: API connection and Premium connection, like TPCQ, HSM etc.
