Dellok HFW Casing Tube J55 N80 L80 P110 Q125 T95 C110 V140 V150
Dellok(YONGHUI Radiating Pipe Manufacturing Co.,Ltd) was established in 2002, which is located in Nanjing, China.We joined HARBIN AIR CONDITIONING CO., LTD. in 2022 and became the most professional industry manufacturer in China. After many years of development, the company now has 66 million yuan in fixed assets, more than 200 employees, and 33 technical staffs. We have 4 aluminum processing production lines, with the annual processing capacity of more than 20,000 tons; And we have 5 tube-drawing production lines; 47 fintube production lines, 1 imported production line from American with the brand of McElroy , with the annual production capacity of 12 million meters the above.
Product Description
| Output | 3.5kw |
| Carrying | 24kgs |
| Height | 100m |
| Cable | Auto |
| Function | lighting |
| Power balance | Auto/Manual |
| Optical com | Optional |
| Anti-shock | Yes |
| Cooling | Normal |
| 4g com | Optional |
| Material | Aluminum |
| Size | 40x30x30cm |
| Weight | 22kgs |
Size
Related Standard & Specification: API 5CT, ISO 11960, API 5B, GOST
Related Grade: J55, K55, N80, L80-1, L80-9Cr, L80-13Cr, P110, Q125, K55 D10, L80 D10.
Available Approved Marine: ABS / BV / LR / DNV / GL / KR, EN10204 3.2 MTC
Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Produce Process: Hot Rolled, Cold Drawn, Hot Expanded.
Accessories: Pup Joint, Coupling (Coupling Stock), Blast Joint, Crossover etc.
Connection: API connection and Premium connection, like TPCQ, HSM etc.
| API Casing | |||||||||||
| Size | Grade and Connection | Standards | |||||||||
| OD mm (in) | WT/mm | H40 | J55 K55 | M65 | L80-1 R95 | N80-1 N80Q | C90 T95 | C110 | P110 | Q125 | |
| 114.3(4.5') | 5.21 | S | S | S | API SPEC 5CT/ISO11960 | ||||||
| 5.69 | S/B | S/B | |||||||||
| 6.35 | S/L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 7.37 | L/B | L/B | L/B | L/B | L/B | ||||||
| 8.56 | L/B | L/B | |||||||||
| 127(5') | 5.59 | S | S | ||||||||
| 6.43 | S/L/B | S/L/B | |||||||||
| 7.52 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 9.19 | L/B | S/L/B | S/L/B | L/B | S/L/B | L/B | |||||
| 11.1 | L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 12.14 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | L/B | ||||||
| 139.7(5.5') | 6.2 | S | S | S | |||||||
| 6.98 | S/L/B | S/L/B | |||||||||
| 7.72 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 9.17 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 10.54 | L/B | S/L/B | S/L/B | L/B | S/L/B | S/L/B | |||||
| 168.28(6.625') | 7.32 | S | S/L/B | S/L/B | |||||||
| 8.94 | S/L/B | L/B | S/L/B | S/L/B | L/B | S/L/B | |||||
| 10.59 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 12.06 | S/L/B | S/L/B | L/B | S/L/B | L/B | ||||||
| 177.8(7') | 6.91 | S | S | S | |||||||
| 8.05 | S/L/B | L/B | S/L/B | S/L/B | L/B | ||||||
| 9.19 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 10.36 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 11.51 | L/B | S/L/B | S/L/B | L/B | S/L/B | ||||||
| 12.65 | S/L/B | S/L/B | L/B | S/L/B | S/L/B | ||||||
| 13.72 | S/L/B | S/L/B | L/B | S/L/B | S/L/B | ||||||
| 193.68(7.625') | 8.33 | S/L/B | S/L/B | L/B | L/B | L/B | |||||
| 9.52 | L/B | L/B | L/B | L/B | L/B | ||||||
| 10.92 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | L/B | ||||||
| 14.27 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.11 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.88 | L/B | L/B | L/B | L/B | L/B | ||||||
| 219.08(8.625') | 6.71 | S | S | S | |||||||
| 7.72 | S | S/L/B | S | ||||||||
| 8.94 | S | S/L/B | S/L/B | ||||||||
| 10.16 | S/L/B | L/B | L/B | L/B | L/B | ||||||
| 11.43 | L/B | L/B | L/B | L/B | L/B | ||||||
| 12.7 | L/B | L/B | L/B | L/B | |||||||
| 14.15 | L/B | L/B | L/B | L/B | L/B | ||||||
| 244.48(9.625') | 8.94 | S | S/L/B | S/L/B | |||||||
| 10.03 | S/L/B | S/L/B | L/B | L/B | L/B | L/B | |||||
| 11.05 | L/B | L/B | L/B | L/B | L/B | ||||||
| 11.99 | L/B | L/B | L/B | L/B | L/B | L/B | |||||
| 13.84 | L/B | L/B | L/B | L/B | L/B | ||||||
| 15.11 | L/B | L/B | L/B | L/B | |||||||
| 273.05(10.75') | 8.89 | S/B | S/B | ||||||||
| 10.16 | S/B | S/B | S/B | ||||||||
| 11.43 | S/B | S/B | S/B | S/B | S/B | S/B | S/B | ||||
| 12.57 | S/B | S/B | S/B | S/B | |||||||
| 13.84 | S/B | S/B | S/B | ||||||||
| 15.11 | S/B | S/B | S/B | ||||||||
| 298.45(11.75') | 9.65 | ||||||||||
| 10.92 | |||||||||||
| 12.19 | S/B | S/B | |||||||||
| 13.06 | S/B | S/B | S/B | ||||||||
| 339.72(13.375') | 8.38 | S | |||||||||
| 9.65 | S/B | S/B | |||||||||
| 10.92 | S/B | S/B | |||||||||
| 12.19 | S/B | S/B | S/B | S/B | S/B | ||||||
| 13.06 | S/B | S/B | S/B | S/B | S/B | ||||||
| 406.4(16') | 16.66 | ||||||||||
| 508(20') | 16.13 | S/L/B | |||||||||
| Note: S-SC;L-LC;B-BC. | |||||||||||
| API Tubing | |||||||||||
| Size | Grade and Connection | Standards | |||||||||
| OD mm (in) | WT/mm | H40 | J55 | L80-1 R95 | N80-1 N80Q | C90 | T95 | P110 | |||
| 42.16(1.66') | 3.18 | API SPEC 5CT/ISO11960 | |||||||||
| 3.56 | N/U | N/U | N/U | N/U | N/U | N/U | |||||
| 4.85 | U | U | U | U | U | U | U | ||||
| 48.26(1.9') | 3.18 | N/U | N/U | N/U | N/U | N/U | N/U | ||||
| 3.68 | N/U | N/U | N/U | N/U | N/U | N/U | |||||
| 5.08 | U | U | U | U | U | U | U | ||||
| 6.35 | |||||||||||
| 7.62 | |||||||||||
| 60.32(2.375') | 4.24 | ||||||||||
| 4.83 | |||||||||||
| 6.45 | |||||||||||
| 7.49 | |||||||||||
| 8.53 | |||||||||||
| 73.02(2.875') | 5.51 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | |||
| 7.01 | N/U | N/U | N/U | N/U | N/U | ||||||
| 7.82 | N/U | N/U | N/U | N/U | N/U | ||||||
| 8.64 | U | U | |||||||||
| 9.96 | |||||||||||
| 11.18 | U | N | N | N | N | N | |||||
| 88.9(3.5') | 5.49 | ||||||||||
| 6.45 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | ||||
| 7.34 | N | N | N | N | N | N | |||||
| 9.52 | N/U | N/U | N/U | N/U | N/U | ||||||
| 10.92 | |||||||||||
| 12.09 | |||||||||||
| 13.46 | |||||||||||
| 101.6(4') | 5.74 | N | N | N | N | N | N | N | |||
| 6.65 | U | U | U | U | U | U | U | ||||
| 8.38 | |||||||||||
| 10.54 | |||||||||||
| 12.7 | |||||||||||
| 15.49 | |||||||||||
| 114.3(4.5') | 6.88 | N/U | N/U | N/U | N/U | N/U | N/U | N/U | |||
| 8.56 | |||||||||||
| 9.65 | |||||||||||
| 10.92 | |||||||||||
| 12.7 | |||||||||||
| 14.22 | |||||||||||
| 16 | |||||||||||
| Note: N-NU; U-EU. | |||||||||||
| Chemical Analysis(%) For Part Standard | ||||||||||||||||
| Standard | Class | Grade | Type | C | Mn | Mo | Cr | Ni | Cu | P | S | Si | ||||
| min | max | min | max | min | max | min | max | max | max | max | max | max | ||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | |
| API 5CT | 1 | H40 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |
| J55 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| K55 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| N80 | 1 | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| N80 | Q | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| 2 | M65 | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | ||
| L80 | 1 | - | 0.43 | - | 1.9 | - | - | - | - | 0.25 | 0.35 | 0.03 | 0.03 | 0.45 | ||
| L80 | 9Cr | - | 0.15 | 0.3 | 0.6 | 0.9 | 1.1 | 8 | 10 | 0.5 | 0.25 | 0.02 | 0.01 | 1 | ||
| L80 | 13Cr | 0.15 | 0.22 | 0.25 | 1 | - | - | 12 | 14 | 0.5 | 0.25 | 0.02 | 0.01 | 1 | ||
| C90 | 1 | - | 0.35 | - | 1.2 | 0.25 | 0.85 | - | 1.5 | 0.99 | - | 0.02 | 0.01 | - | ||
| C90 | 2 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.01 | - | ||
| C95 | - | - | 0.45 | - | 1.9 | - | - | - | - | - | - | 0.03 | 0.03 | 0.45 | ||
| T95 | 1 | - | 0.35 | - | 1.2 | 0.25 | 0.85 | 0.4 | 1.5 | 0.99 | - | 0.02 | 0.01 | - | ||
| T95 | 2 | - | 0.5 | - | 1.9 | - | - | - | - | 0.99 | - | 0.03 | 0.01 | - | ||
| 3 | P110 | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | |||
| 4 | Q125 | 1 | - | 0.35 | - | 1.35 | - | 0.85 | - | 1.5 | 0.99 | - | 0.02 | 0.01 | - | |
| Q125 | 2 | - | 0.35 | - | 1 | - | NL | - | NL | 0.99 | - | 0.02 | 0.02 | - | ||
| Q125 | 3 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.01 | - | ||
| Q125 | 4 | - | 0.5 | - | 1.9 | - | NL | - | NL | 0.99 | - | 0.03 | 0.02 | - | ||
| Tensile Property For Part Standard | |||||||||||
| Standard | Class | Grade | Type | Elongation(%) | Yield Strengh(Mpa) | Tensile Strengh(Mpa) | Hardness(Max) | Required WT | Allowed Tolerance of Hardness | ||
| Min | Max | Min | HRC | HBW/- | mm | HRC | |||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | |
| API 5CT | 1 | H40 | 0.5 | 276 | 552 | 414 | - | - | - | - | |
| J55 | - | 0.5 | 379 | 552 | 517 | - | - | - | - | ||
| K55 | - | 0.5 | 379 | 552 | 655 | - | - | - | - | ||
| N80 | 1 | 0.5 | 552 | 758 | 689 | - | - | - | - | ||
| N80 | Q | 0.5 | 552 | 758 | 689 | - | - | - | - | ||
| 2 | M65 | - | 0.5 | 448 | 586 | 586 | 22 | 235 | - | - | |
| L80 | 1 | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| L80 | 9Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| L80 | 13Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | - | - | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | ≤12.70 | 3 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | 12.71~19.04 | 4 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | 19.05~25.39 | 5 | ||
| C90 | 1,2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | ≥25.40 | 6 | ||
| C95 | - | 0.5 | 655 | 758 | 724 | - | - | - | - | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | ≤12.70 | 3 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | 12.71~19.04 | 4 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | 19.05~25.39 | 5 | ||
| T95 | 1,2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | ≥25.40 | 6 | ||
| 3 | P110 | - | 0.6 | 758 | 965 | 862 | - | - | - | - | |
| 4 | Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | ≤12.70 | 3 | |
| Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | 12.71~19.04 | 4 | ||
| Q125 | 1~4 | 0.65 | 862 | 1034 | 931 | - | - | ≥19.05 | 5 | ||
FAQ
1.Does tubing fit inside casing?
Tubing has a smaller outer diameter than the inner diameter of casing,therefore tubing can fit inside casing.4 1/2 inches is the threshold for maximum tubing size or minimumcasing size.
2.How much does steel casingpipe cost?
Steel Casing Pipe cost is lower than drill pipe or the OCTG tubing cost, it is usually higher 200 USD than the regular API 5L pipe.
