DELLOK Best Selling Aluminium Extruded Fin Tubes

1 Piece
$10 - 1000 /Piece/Pieces
DELLOK Best Selling Aluminium Extruded Fin Tubes
Features Gallery Product Description Request A Quote
Application: Heat Exchanger, Condenser, Evaporator, Intercooler
Certificate: ISO9001, CE, RoHS
Fin Height: 6mm-25mm
Fin Pitch: 2.5mm-15mm
Fin Thickness: 0.2mm-1.2mm
Fin Type: Plain, Serrated, Louvered, Perforated
Material: Aluminum, Copper, Carbon Steel, Stainless Steel
Pressure: Low Pressure, High Pressure
Surface Treatment: Polishing, Anodizing, Galvanizing, Powder Coating
Temperature: Low Temperature, High Temperature
Tube Diameter: 6mm-219mm
Tube Length: Customized
Tube Shape: Round, Square, Rectangle
Tube Thickness: 0.5mm-5mm
Basic Infomation
Place of Origin: China
Brand Name: Dellok Yonghui
Certification: ISO90001
Model Number: Extruded Fin Tube
Payment & Shipping Terms
Packaging Details: wooden box
Delivery Time: 1-3 weeks
Payment Terms: T/T, MoneyGram, D/P, D/A, L/C
Supply Ability: 10000 Piece/Pieces per Month
Product Description


DELLOK Best Selling Aluminium Extruded Fin Tubes



About us


Professional heat exchanger factory with 20 years of experience, providing you with one-stop heat transfer solutions to design different heat exchangers according to your purposes (metallurgy, food, petrochemical, pharmaceutical, beverage, wastewater, refrigeration, etc...)

Dellok Young is a professional manufacturer of various heat exchangers integrating R&D, design, production and sales. The heat exchangers produced are mainly used in petrochemical, electric power, papermaking, building heating, mining and other industries, such as air heaters, food industry plant protein powder, starch and other air heater spray drying systems.

The company now has a professional technical innovation team and professional after-sales personnel. The company's production plant covers an area of approximately 18,000 square meters, has multiple professional and advanced CNC and automated production equipment, and has obtained a number of professional certificates and patents.
The company has a professional foreign trade team and has trade cooperation with various regions. Some global partners conducted on-site inspections of the production plants and were very satisfied with the inspection results and established long-term strategic cooperative relationships with our company.



Product Name:Best Selling China Supplier Aluminium Extruded Fin Tube

Product model: AJX1000Z164

Link description: The product pictures displayed on the page are for reference only. The specific product model, size, specification, material and other technical information need to be customized according to your needs.

Extruded Finned Tube Advantage:
1. Optimized inner to outer surface ratio
2. High heat exchange rate
3. Enhanced structure due to the roll forming process
4. Flexible as straight tube or bent or coiled heat exchangers
5. Low heat resistance between fins and tube
6. Strong resistance to shock and thermal expansion and contraction
7. Cost and energy saving due to long service life and high exchange rate


Made of standard grade aluminum or copper, the provided Extruded Aluminum Fin Tubes are widely used as indispensable components for heater or heat exchanging equipments. The smooth design of the fin part of these tubes has simplified their cleaning process. The anodized surface finishing of their fins act as the perfect barrier against corrosion. These fin tubes are completely protected against thermal shock, have necessary heat transferring surface, can endure mechanical shock and deliver outstanding thermal performance. Featured with anti corrosion design, these Extruded Aluminum Fin Tubes can withstand high temperature, corrosion prone working environment and extreme pressure. These remain functional for longer period.

Product Categories : Extruded Finned Tube




Extruded finned tube features:


The finned tube provide by us is Extruded Type, which is different from the ones through HF Welding and Wrapping method. The fins are obtained by roll forming the outer surface of a soft seamless plain tube. The technology simply squeezes the wall thickness transforming into straight fins on the tube. So the fin and the tube are integrated and inseparable, which avoids the heat resistance between fin and tube, and optimizes heat exchange efficiency. Based on this structure, the Extruded type can survive more severe working conditions than other finned tubes. Also it, on the other hand, shows several unique features such as enhanced physical structure, resistance to vibration, anti-corrosion ability, and long service life, etc.

Extruded Finned Tube

Under this technology, there are two major types of finned tubes available with us, Single metal tubes and Bimetallic tubes. The former uses Copper, Aluminum, and Copper Nickel alone. The later has a core tube on the inside made of harder material. In this case, the outer tube is rolled onto the core tube in order to provide for a tight bond and good thermal contact between the two tubes.

Extruded Aluminum Tubing

Customized finned tube is available. The specification table is followed below. If required, the fin tube can be made into various forms after soft annealing process. They can be used for cooling and heating in a large scale of conditions. For example, coils in water heater, oil cooler in large machines, heat transfer part in boiler and heat recovering system, air-conditioning and refrigeration industry as condenser part or evaporator part, etc.

Aluminum Extruded Tubing

The material for our fin tube covers Copper(C10200, C12000, C12200), Copper Nickel(C70600), Aluminum(1060), Aluminum alloy, Aluminum-Steel(bimetallic), Aluminum-Stainless Steel(bimetallic), Aluminum-Copper(bimetallic), Aluminum-Copper Nickel(bimetallic), Copper-Copper Nickel(bimetallic).


Extruded Fin Tubes







1. Optimized inner to outer surface ratio

2. High heat exchange rate

3. Enhanced structure due to the roll forming process

4. Flexible as straight tube or bent or coiled heat exchangers

5. Low heat resistance between fins and tube

6. Strong resistance to shock and thermal expansion and contraction

7. Cost and energy saving due to long service life and high exchange rate





Extruded Finned Tube Specifications:


Extruded Fin Tubes





Finned Tube





Product Description:



The fin tubes available with us covers Integrated Finned Tube of Copper (C10200, C12000, C12200),Cupronickel (C70600), Aluminum (1060) and Aluminum Alloy (AISI6063), Bimetallic Finned Tube such as Copper - Aluminum, Copper Alloy - Aluminum, Steel – Aluminum, Stainless Steel – Aluminum,Laser Welded Fin Tube using Stainless Steel and Titanium.
We have a wide and comprehensive range of products, and we can produce all the relevant types of products in the market.

As shown in the figure below:



DELLOK Best Selling Aluminium Extruded Fin Tubes 6






Product Packaging:



We can package the products according to the customer's requirements to ensure the safe arrival of the products in all kinds of transportation scenarios. If you have special requirements on packaging, please contact us.

DELLOK Best Selling Aluminium Extruded Fin Tubes 7







1. What Does Fin Tube Mean?

A fin tube is a tube that has small fins around the outside surface. These fins act as a filter and a mechanism to transfer heat from the material inside the tube to the outside space or vice versa. Fin tubes are used in applications that require a transfer of heat from a hot fluid to a colder fluid through the tube's wall. The rate at which such heat transfer occurs depends on three factors:

The temperature difference between the two fluids.

The heat transfer coefficient between each of the fluids and the tube wall.

The surface area to which the fluid is exposed.


2. Where is finned tube heat exchanger used?

Finned tube heat exchangers generally use air to cool or heat fluids such as air, water, oil or gas, or they can be used to capture or recover waste heat. These heat exchangers can used in a broad range of industries including oil & gas, power generation, marine and HVAC&R.


3. What is extruded fin tube?

Extruded finned tubes are bimetallic tubes whose outer aluminium surface is finned by cold plastic deformation. There are two major types of finned tubes available with us, single metal tubes (also called mono metallic fin tube) and Bimetallic tube (composite extruded fin tube) .


4. Why Aluminium is recommended as a fin material?

Good corrosion resistance, formability and high thermal conductivity make aluminium an ideal material for the construction of these heat exchangers. A typical brazed heat exchanger (radiator or condenser) comprises fins, tubes, sideplates and headerplates.

5. Where are extruded fin tubes used?

Extruded Fin Tubes are widely used in the refinery, petrochemical and chemical industry for:

Air-cooled condensers

Air-cooled coolers for products

Gas coolers

Gas heaters
