DELLOK YONGHUI Aluminum Embedded Fin Tube

Name: DELLOK YONGHUI Aluminum Embedded Fin Tube
Brand: Dellok Yonghui Radiating Pipe Manufacturing Co.,Ltd.
SKU: Aluminum profile
Price: 505.00 USD
Availability: InStock

Brand Name:	DELLOK Yonghui
Model Number:	Aluminum profile
MOQ:	1 meter
Price:	$10 - 1000 /Piece/Pieces
Delivery Time:	1-3weeks
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Tolerance:

0.001

Packaging:

Laminating

Range Of Applications:

Wide

Antioxidant:

Strong

Performance:

Corrosion Resistant And Easy To Process

Corrosion Resistant:

Strong

Color:

Customizable

Weighing Method:

Weighing/Counting

Packaging Details:

Wooden Case

Supply Ability:

10000 Piece Monthly

Highlight:

Plant light strip radiator aluminum profile

Light Strip Radiator Aluminum Profile

Product Description

DELLOK Aluminum Embedded Fin Tube For Boiler

1. Brand Strength: 20-Year Expert in Heat Exchange, Quality Guaranteed

DELLOK is a professional heat exchanger manufacturer integrating R&D, design, production, and sales, with 20 years of industry experience. Our production base covers an area of approximately 18,000 square meters, equipped with multiple sets of advanced CNC and automated production equipment. We also have a professional technical innovation team and after-sales service team.

We provide one-stop heat transfer solutions for various industries such as metallurgy, food, petrochemical, pharmaceutical, and refrigeration. Our products are sold worldwide, and many international partners have established long-term strategic cooperation with us after on-site inspections, which proves our strength is recognized by the market.

2. Core Product Highlights: Customized for Boiler Working Conditions, Outstanding Performance

1. Innovative Embedded Forming Process, More Stable Structure

Adopting mechanical embedded forming process: First, precisely groove the outer diameter of the base tube, guide the root of the aluminum fin strip into the groove, and then lock the fin by rolling to close the groove, forming a seamless and firm structure.

Compared with traditional welded finned tubes, it can effectively resist vibration and continuous thermal cycling, and the fins are not easy to fall off. Its temperature resistance is much higher than that of aluminum L-foot finned tubes, with a maximum applicable temperature of 450°C, perfectly adapting to the high-temperature working environment of boilers.

3. Efficient Heat Transfer, Cost-Effective Choice

The fin and tube wall maintain constant contact, with low thermal resistance, significantly improving heat transfer efficiency;

The fin is fixed along its entire length, so it will not loosen even if partially damaged, extending the service life;

It balances performance and cost, with outstanding cost-effectiveness in boiler heat transfer scenarios, making it the preferred component for efficient heat transfer.

4. Core Specifications: Flexible Adaptation to Diverse Needs

Item

Specification Range

Base Tube Outer Diameter:19~51mm (3/8”~2”)

Base Tube Wall Thickness:2.11~3.5mm (0.083”~0.138”)

Base Tube Length:≤18500mm (≤60.7ft)

Fin Thickness:0.3~0.5mm (0.012”~0.02”)

Fin Height:10~16mm (0.394”~0.63”)

Fin Pitch:3~11FPI (100~433FPM)

Optional Base Tube Materials

Carbon Steel (A179/A192, etc.), Stainless Steel (TP304/316, etc.), Copper Alloy, etc.

Fin Material:Aluminum (Common grades: Alu.1100, Alu.1060, Alu.6063, etc.)

5. Application Scenarios: Focus on Boilers, Covering Multiple Industries

As the core heat transfer component of boiler systems, it can greatly improve heat exchange efficiency and is widely used in:

Power Industry: Heat exchange systems of power plant boilers;

Petrochemical Industry: Boiler equipment in refineries and chemical plants;

Others: Industrial boiler scenarios in steel plants, fertilizer plants, etc., especially suitable for medium-high temperature working conditions with high requirements for heat transfer stability.

6. Quality Assurance: Strict Control in Multiple Links, Rest Assured to Choose

Raw Material Control: Conduct incoming inspection on base tubes and fin strips, and provide raw material mill test certificates (MTC);

Production Supervision: Conduct full-process production inspection and real-time monitoring of key links;

Finished Product Testing: Carry out water pressure test and fin bonding strength test (hanging a 3kg weight to check fin firmness);

Third-Party Certification: Support customers to entrust third-party institutions for testing to ensure products meet standards.

7. Contact Us

If you need customized aluminum embedded fin tubes for boilers or want to know more product details, please feel free to contact DELLOK's foreign trade team. We will provide you with professional solutions!
