| Pitch Of Fins | 2.3-12mm; |
|---|---|
| Type | Fin Tube |
| OD | φ 38.1-φ77m |
| Tube Length | 0.5~ 14m. |
| Material | Aluminum Alloy / Copper |
| Tube OD | 50.8mm(2'') Max. |
|---|---|
| Tube Length | 18,000mm Max. |
| Fin Height | 16.5 Mm Max. |
| Fin Thickness | Generally 0.4mm ~0.6mm |
| Manufacturing Process | The Aluminum Fin Strip Is Tension Wound And Placed Into A Groove Cut Into The Tube With Appr. 0.4mm Fluted Depth. |
| Tube OD | 12mm Min.~50.8mm(2'') Max. |
|---|---|
| Fins Type | Solid Or Serrated |
| Fin Material | Aluminum 1050/1060/1070/5052/6063 |
| Fin Pitch | Min. 1.5mm |
| Fin Thickness | 0.4mm Avergae |
| Tube OD | 12mm Min.~50.8mm(2'') Max. |
|---|---|
| Tube Length | No Limit |
| Fin Height | 16 Mm Max. |
| Fin Thickness | Appr. 0.4mm/0.5mm/0.6mm |
| Fin Material | Aluminum 1050, 1060,1070,1100,6063 |
| Tube OD | 50.8mm Max. |
|---|---|
| Tube Length | No Limit |
| Fin Height | 16 Mm Max. |
| Fin Thickness | Generally 0.4mm ~0.6mm |
| Fin Pitch | 13FPI Min. |
| Fin Tube Type | Knurled Fin Tubes Or Aluminum Refrigerant Piping |
|---|---|
| Outer Surface Of Plain Tubes | Knurled |
| Fin Type | Solid Plain |
| Tube OD | 50.8mm Max. |
| Tube Length | 18,000mm Max. |
| Tube OD | 50.8mm Max. |
|---|---|
| Tube Length | No Limit. |
| Fin Height | 16 Mm Max. |
| Fin Pitch | 2.1 Mm (12FPI) Min. |
| Fin Tube Type | LL Overlapped Type Fin Tube |
| Fin Tube Type | High Frequency Welded Fin Tube Or HF Welding Fin Tube |
|---|---|
| Tube OD | 19mm Min. |
| Tube Length | 18 Meters Max. |
| Fin Height | 32 Mm Max. |
| Fin Thickness | 0.8mm Min |
| Tube OD | 50.8mm Max. |
|---|---|
| Fin Material | Alu. 1050/1060/1100 & Copper |
| Tube Wall Thk | No Limit |
| Fin Pitch | 12FPI |
| Fin Thk | 0.4mm Average |
| Application | Heat Exchanger |
|---|---|
| Fin Angle | 45° |
| Fin Height | 2mm |
| Fin Length | 100mm |
| Fin Number | 50 |
